Overview

Floor convector radiators are a modern and efficient heating solution designed to provide comfortable indoor temperatures while maintaining a sleek and unobtrusive aesthetic. Installed at or slightly below floor level, these radiators use the principle of convection to circulate warm air throughout a space. They are especially popular in buildings with large windows or areas where wall-mounted radiators are not practical.

Parameter

AHK340/150 Double pipe type

Model			AHK340/150-1250			AHK340/150-2000			AHK340/150-2750
Speed level			3	2	1	3	2	1	3	2	1
Air flowm³h			287	197	105	574	394	210	861	591	315
Sound pressure level dB(A)			37	25	20	39	27	21	40	28	22
Power level(W			46	32	18	92	64	36	138	96	54
Number of motors			1			2			3
Water temperature(c	room temperature(C)		Heating capacity(W)			Heating capacity(W			Heating capacity(W)
95/70	18		4949	3575	2548	9713	7014	4997	14427	10390	7403
95/70	20		4796	3464	2470	5412	6796	4842	13980	10067	7173
80/60	18		3990	2882	2055	7830	5654	4028	11630	8375	5967
80/60	20		3837	2771	1976	7529	5436	3874	11183	8053	5738
75/60	18		3798	2743	1956	7454	5382	3835	11070	7972	5680
75/60	20		3644	2633	1877	7152	5164	3679	10623	7650	5450
70/55	18		3415	2466	1758	6701	4838	3447	9951	7167	5107
70/55	20		3261	2355	1679	6399	4621	3292	9504	6845	4877
60/45	18		2647	1912	1363	5194	3750	2672	7715	5556	3958
60/45	20		2493	1801	1283	4892	3533	2517	7268	5234	3729
Water temperature(℃)	room temperature(C)		Heating capacity(w)			Heating capacity(W			Heating capacity(W)
6/12	26	Qk	1434	1036	739	2814	2032	1448	4180	3010	2145
	26	Qs	1205	870	621	2364	1707	1217	3512	2529	1802
	24	Qk	1121	809	577	2198	1587	1131	3264	2351	1675
	24	Qs	1084	783	558	2127	1536	1094	3159	2275	1621
8/14	26	Qk	1084	783	558	2127	1536	1094	3159	2275	1621
	26	Qs	1084	783	558	2127	1536	1094	3159	2275	1621
	24	Qk	873	630	449	'712	1237	881	2543	1832	1305
	24	Qs	873	630	449	712	1237	881	2543	1832	1305
10/15	26	Qk	890	644	459	.747	1262	899	2595	1868	1331
	26	Qs	890	644	459	747	1262	899	2595	1868	1331
	24	Qk	764	552	393	-499	1082	771	2226	1603	1142
	24	Qs	764	552	393	1499	1082	771	2226	1603	1142
12/16	26	Qk	782	565	403	535	1108	789	2279	1641	1169
	26	Qs	782	565	403	1535	1108	789	2279	1641	1169
	24	Qk	659	476	339	292	933	665	1919	1382	985
	24	Qs	749	476	339	292	933	665	1919	1382	985
16/18	26	Qk	576	417	297	130	816	582	1679	1210	862
	26	Qs	576	417	297	1130	816	582	1679	1210	862
	24	Qk	469	338	241	920	664	473	366	984	701
	24	Qs	469	338	241	920	664	473	1366	984	701
The length of the heat dissipation element of all models in the table is L-250mm. In addition to the above standard models, our company can customize them according to the specific building and heat dissipation requirements. Qk-total cooling capacity; Qs: sensible cooling capacity

AHK340/150 four pipe type

Model			AHK340/150-1250			AHK340/150-2000			AHK340/150-2750
Speed level			3	2	1	3	2	1	3 2		1
Air flow m³h			287	197	105	574	394	210	861 591		315
Sound pressure level dB(A)			37	25	20	29	27	21	40 28		22
Power level(W			46	32	18	92	64	36	138 96		54
Number of motors			1			2			3
Water temperature(c	room temperature(C)		Heating capacity(W)			Heating capacity(W			Heating capacity(W)
95/70	18		2870	2074	147	5633	4068	2898	8367 6026		4294
95/70	20		2782	2009	1433	5459	3942	2808	8108 5839		4161
80/60	18		2314	1671	1192	4541	3280	2336	6746 4858		3461
80/60	20		2226	1607	1146	4367	3153	2246	6486 4671		3328
75/60	18		2203	1591	1134	4324	3121	2224	6421 4624		3294
75/60	20		2113	1527	1088	4148	2995	2134	6161 4437		3161
70/55	18		1981	1430	1020	3886	2806	1999	5772 4157		2962
70/55	20		1891	1366	974	3712	2680	1910	5513 3970		2829
60/45	18		1535	1109	790	3012	2175	1550	4475 3222		2296
60/45	20		1446	1045	744	2838	2049	1460	4216 3036		2163
Water temperature(c	room temperature(C)		Heating capacity(W)			Heating capacity(W			Heating capacity(W)
6/12	26	Qk	1147	829	591	2252	1625	1158	3344	2408	1715
	26	Qs	964	697	497	1892	1366	974	2810	2023	1442
	24	Qk	896	647	462	1759	1269	905	2612	1881	1340
	24	Qs	867	626	445	1701	1229	876	2527	1820	1297
8/14	26	Qk	867	626	446	1701	1229	876	2527	1820	1297
	26	Qs	867	626	446	1701	1229	876	2527	1820	1297
	24	Qk	698	504	359	1370	989	705	2034	1465	1044
	24	Qs	698	504	359	1370	989	705	2034	1465	1044
10/15	26	Qk	712	515	367	1398	1010	719	2075	1495	1065
	26	Qs	712	515	367	1398	1010	719	2075	1495	1065
	24	Qk	611	441	315	1199	866	617	1780	1283	914
	24	Qs	611	441	315	1199	866	617	1780	1283	914
12/16	26	Qk	626	452	322	1228	887	632	1823	1312	935
	26	Qs	626	452	322	1228	887	632	1823	1312	935
	24	Qk	527	381	272	1034	747	532	1535	1106	788
	24	Qs	527	381	272	1034	747	532	1535	1106	788
16/18	26	Qk	461	333	238	905	653	466	1344	968	689
	26	Qs	461	333	238	905	653	466	1344	968	689
	24	Qk	375	271	193	736	531	379	1093	787	561
	24	Qs	375	271	193	736	531	379	1093	787	561
The length of the heat dissipation element of all models in the table is L-250mm. In addition to the above standard models, our company can customize them according to the specific building and heat dissipation requirements. Qk-total cooling capacity; Qs: sensible cooling capacity

Natural convection type

Cooling and heating type

Advantages of Floor Convector Radiators

◆Space-Saving Design: Installed flush with the floor, they free up wall space for furniture or décor.

◆Enhanced Aesthetics: Discreet and low-profile, they seamlessly blend into the surrounding environment.

◆Efficient Heating: Provides even heat distribution without creating cold spots.

◆Prevents Cold Drafts: Especially effective when placed near large windows to counteract heat loss.

◆Safe and Child-Friendly: The heating surface is typically not exposed, making it safer for households with children or pets.

◆Energy Efficient: Consumes less energy compared to traditional radiators, especially when equipped with smart thermostatic controls.

◆Flexible Installation: Available in various sizes and configurations to fit different room layouts.

Applications of Floor Convector Radiators

Floor convector radiators are highly versatile and ideal for a wide range of applications:

◆Residential Spaces

Perfect for modern homes, apartments, and townhouses, especially in rooms with large glass windows or patio doors.

◆Commercial Buildings

Suitable for office spaces, retail stores, and showrooms where maintaining a clean aesthetic is important.

◆Conservatories and Sunrooms

Prevents cold air from entering by counteracting heat loss around windows.

◆Lobbies and Reception Areas

Commonly installed in hotels, airports, and commercial buildings to maintain a warm and welcoming atmosphere.

◆Healthcare and Educational Facilities

Used in hospitals, clinics, and schools where safety, comfort, and hygiene are key.

◆Industrial Spaces

Provides efficient heating in warehouses, factories, and other large, open environments.

.jpg


product-907-456
